HFXP120 Crawler Type Jet Grouting Anchor Drilling Rig
- Drilling Diameter: 90-185mm
- Drilling Depth:0-50m(rotary jet grouting drilling);0-80m(anchor drilling)
- Engine Power:30+11+3kW
- Traveling Speed:12m/min
product Introduction
Rotary jet grouting anchor drilling rig is used for conveying slurry, compressed air and clean water under high pressure working condition, to ensure the continuous dynamic density and static density. The main components adopt latest group technology and new-design hydraulic system. With full hydraulic control, instrument display, easy and flexible operation, it greatly improve the work efficiency to meet the needs of customers.
Features
- 1Easy construction, enhanced mine crawler chassis, walking is more efficient, stable and more dynamic in complex road conditions.
- 2Wide range of strata. Different performance configurations can be made according to different stratum. Maximum output torque reaches up to 3600 N.m, and the maximum pull force reaches to 60 KN. The drilling technologies of carbide drill bit rotary drilling, DTH hammer impact drilling and tricone bit drilling are optional, thus ensuring the immediate rotary jet grouting into piles after drilling a hole in most strata.
- 3It can be used for not only rotary jet grouting drilling, but for anchor drilling.
- 4Multiple configuration parts. Customers can choose different performance modules according to different project development needs, which can be purchased at a time, or configured again according to the continuous development of the project.
- 5 Easy operation and maintenance. Due to the use of full hydraulic technology, there is a breakthrough in the key technologies, such as rotary jet lifting, anchoring weekly speed module, so the operation is more convenient.
- 6Fully equipped drilling tools. According to the market demand, we have developed a large number of rotary jet drilling machines to meet the needs of users, such as single, double, triple, fixed jet, pendulum jet drilling tools.
- 7The height of drilling rig can be customized according to the different needs of customers, and different single, double and triple modules can be made according to different construction requirements.
Application
It is widely applicable for all kinds of soft foundation reinforcement, anti-seepage treatment of basement of high-rise buildings, levee improvement of big river and railway, highway and bridge pier reinforcement, etc.
TECHNICAL DATA
| Rotary Jet Grouting Drilling |
|
| Pile Diameter |
Single: 400-600mm |
| Double: 600-1200mm |
|
| Triple: 800-1600mm |
|
| Hole Depth |
0-50m |
| Hole Diameter |
90-185mm |
| Anchor Drilling |
|
| Hole Depth |
0-80m |
| Drilling Angle |
0-90degree |
| Rotary Jet Grouting Anchor Drilling |
|
| Rotation Speed |
0-20r/min(adjustable) |
| Lifting Force of Power Head |
80KN |
| Drilling Rod Length |
1/1.5/2m(optional) |
| Walking Speed |
12m/min |
| Engine Power |
30+11+3kw |
| Transportation Dimension |
4700*1900*2200mm |
| Total Weight |
About 4000kg |
